An oscilloscope is a laboratory instrument commonly used to display and analyze the waveform of electronic signals. In effect, the device draws a graph of the instantaneous signal voltage as a function of time. UNI-T UTD2072CEX-II digital oscilloscope is a 2 channel 70MHz bandwidth high-performance device. It has a sampling rate of 1GS/s. Digital Storage CRO is ergonomic, lightweight, universal instruments designed for engineers. Sampling Oscilloscope is suitable for field testing and analyzing time-based voltage signals in a mobile environment
Features Of UNI-T UTD 2072CEX-II Oscilloscope DSO Scopemeter:
- 70MHz bandwidth, 1GSa/s real-time sampling rate
- 2 channels
- 25kpts memory depth
- 20,000wfms/s waveform acquisition rate
- 2ns/div~50s/div time-base
- Trigger modes: Edge, Pulse Width, Runt, Over-amplitude, Slope and Video
- Calibration Signal Output: 10Hz, 100Hz, 1kHz (default), 10kHz and 100kHz
- Input calibration signal only by pressing a button
- 10Mpts waveform recording
- 8-inch TFT LCD, WVGA (800×480)
- USB OTG and Pass/Fail interfaces
Specifications Of 2 Channel Digital Storage Oscilloscope:
- Channels: 2
- Bandwidth: 70MHZ
- Sample Rate: 1GS/s
- Rise Time: ≤5ns
- Memory Depth: 25 kpts
- Waveform Acquisition Rate: ≥2000wfms/s
- Vertical Sensitivity: 1mV/div-20V/div (1MΩ)
- Time-base Range: 2ns/div~50s/div
- Storage: Setup, Wave, Bitmap
- Trigger Modes: Edge, Pulse, Video, Slope, Alternate
- Interface: USB OTG,Pass/Fail
- Power: 100-240VAC, 40-440Hz
- LCD Size: 7 Inches 64K Color TFT LCD, 800×480
- Color: White and Grey
- Dimension: 306mm ×147mm × 122mm
Package Include:
- 1x Oscilloscope
- 2x Probe (1×,10× switchable)
- 1x power cord
- 1x USB cable
